13 SERVICE WORK ON THE CHASSIS
110
Z03268-10
–
Remove screws
2
.
Z03269-10
–
Remove screws
3
.
Z03270-10
–
Remove engine guard
4
.
Guideline
Pull the damping rubbers out of the cut-outs on both sides.
13.30 Installing the engine guard
Z03271-10
– Position the engine guard.
Damping rubbers
A
engage in cut-outs
B
on both
sides.
Z03269-11
–
Mount screws
1
, but do not tighten yet.
Guideline
Screw, engine
guard
M6x10 10 Nm (7.4 lbf ft)
Loctite
®
243™
