COMBINATION INSTRUMENT 7
37
8
Heated grip (optional) ( p. 41)
9
Unit for the speedometer
bk
MTC display ( p. 40)
bl
ABS display ( p. 40)
bm
Favorites display ( p. 42)
bn
Fuel range display
bo
Fuel level display ( p. 41)
bp
Ambient air temperature indicator ( p. 39)
bq
Speedometer ( p. 39)
7.8 Rally display (optional)
I00201-10
Info
The figure shows the start screen of the combination instrument in active riding mode Rally (optional). If
the menu is open, the speed and the selected gear are still displayed.
1
Fuel level display ( p. 41)
2
Speed ( p. 38)
2
Shift warning light ( p. 38)
The shift warning light is integrated in the tachometer display.
3
Slip adjustment (optional) ( p. 145)
4
Time ( p. 39)
5
Coolant temperature indicator ( p. 40)
6
Speedometer ( p. 39)
7
Unit for the speedometer
