30 LIST OF SYMBOLS
176
30.1 Red symbols
Red symbols indicate an error condition that requires immediate intervention.
The oil pressure warning lamp lights up red – The oil pressure is too low. Stop immediately,
taking care not to endanger yourself or other road users in the process, and switch off the
engine.
30.2 Yellow and orange symbols
Yellow and orange symbols indicate an error condition that requires prompt intervention. Active driving aids are
also represented by yellow or orange symbols.
The malfunction indicator lamp lights up yellow – The OBD has detected a malfunction in the
vehicle electronics. Come safely to a halt, and contact an authorized KTM workshop.
ABS warning lamp lights up yellow – Status or error messages relating to ABS.
The ABS rear warning lamp lights up yellow – ABS is deactivated on the rear wheel.
TC indicator lamp lights up/flashes yellow – MTC ( p. 144) is not enabled or is currently
intervening. The TC indicator lamp also lights up if a malfunction is detected. Contact an
authorized KTM workshop. The TC indicator lamp flashes, if MTC or MSR (optional) actively
engage.
The cruise control system indicator lamp (optional) lights up yellow – The cruise control sys-
tem function is switched on, but cruise control is not activated.
The general warning lamp lights up yellow – A note/warning note on operating safety has been
detected. This is also shown in the display.
Hazard warning flasher indicator lamps – The hazard warning flasher is switched on.
30.3 Green and blue symbols
Green and blue symbols reflect information.
The turn signal indicator lamp flashes green simultaneously with the turn signal – The turn
signal is switched on.
The idle indicator lamp lights up green – The transmission is in neutral.
The cruise control system indicator lamp (optional) lights up green – The cruise control sys-
tem function is switched on and cruise control is activated.
The high beam indicator lamp lights up blue – The high beam is switched on.
