23.2 Engine tightening torques
Screw plug, water pump drain hole EJOTALtracs
®
Plus 60x14 8 Nm (5.9 lbf ft)
Loctite
®
243™
Screw, bleeder flange EJOTALtracs
®
M6x12 8 Nm (5.9 lbf ft)
Loctite
®
243™
Hose clamp, intake flange M4 2.5 Nm (1.84 lbf ft)
Nozzle, engine vent M5 2 Nm (1.5 lbf ft)
Oil nozzle for piston cooling M5 2 Nm (1.5 lbf ft)
Oil nozzle in cylinder head M5 2 Nm (1.5 lbf ft)
Remaining screws, engine M5 6 Nm (4.4 lbf ft)
Screw, cam lever axial lock M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, crankshaft speed sensor M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, gear position sensor M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, oil filter cover M5 6 Nm (4.4 lbf ft)
Screw, pressure plate M5 3 Nm (2.2 lbf ft)
Loctite
®
243™
Screw, shift drum retaining bracket M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, shift shaft sensor M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Screw, thermostat case M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Securing screw, balancer shaft M5 5 Nm (3.7 lbf ft)
Loctite
®
243™
Swing angle sensor screw M5 6 Nm (4.4 lbf ft)
Loctite
®
243™
Nut, starter motor cable M6 5 Nm (3.7 lbf ft)
Remaining screws, engine M6 10 Nm (7.4 lbf ft)
Screw, alternator cover M6x30 10 Nm (7.4 lbf ft)
Screw, alternator cover M6x35 10 Nm (7.4 lbf ft)
Screw, camshaft bearing bridge M6 10 Nm (7.4 lbf ft)
Screw, clutch cable retaining
bracket
M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, clutch cover M6 10 Nm (7.4 lbf ft)
Screw, clutch release lever M6 10 Nm (7.4 lbf ft)
Loctite
®
243™
Screw, clutch spring M6 8 Nm (5.9 lbf ft)
Screw, cylinder head M6 10 Nm (7.4 lbf ft)
Screw, engine case M6x30 12 Nm (8.9 lbf ft)
Screw, engine case M6x60 12 Nm (8.9 lbf ft)
Screw, freewheel ring M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, ignition coil M6 8 Nm (5.9 lbf ft)
