TECHNICAL SPECIFICATIONS 23
161
front 1.8 bar (26 psi)
rear 1.8 bar (26 psi)
Tire pressure full payload
front 2.6 bar (38 psi)
rear 2.9 bar (42 psi)
Secondary drive ratio 16:45
Chain 5/8 x 1/4” (520) X‑ring
Steering head angle 63.7°
Wheelbase 1,528 mm (60.16 in)
Seat height, unloaded 880 mm (34.65 in)
Ground clearance, unloaded 263 mm (10.35 in)
Weight without fuel, approx. 200 kg (441 lb.)
Maximum permissible front axle load 175 kg (386 lb.)
Maximum permissible rear axle load 275 kg (606 lb.)
Maximum permissible total weight 450 kg (992 lb.)
23.5 Electrical system
12-V battery HTZ12A-BS Battery voltage: 12 V
Nominal capacity: 10 Ah
Maintenance-free
Fuse 75011088010 10 A
Fuse 75011088015 15 A
Fuse 75011088025 25 A
Fuse 58011109130 30 A
Low beam/high beam LED
Daytime running light/position light LED
Combination instrument lighting and indicator lamps LED
Turn signal LED
Brake/tail light LED
License plate lamp LED
23.6 Tires
Front tire Rear tire
90/90 - 21 M/C 54T M+S TL
Continental TKC80 Twinduro
150/70 - 18 M/C 70Q TL
Continental TKC80 Twinduro
The tires specified represent one of the possible series production tires. For alternative manufacturers, if any,
contact an authorized dealer or qualified tire dealership. If local road approval regulations apply, these and the
respective technical specifications must be observed. Additional information is available in the Service section
under:
KTM.COM
