COMBINATION INSTRUMENT 7
41
Info
If the coolant temperature indicator shows HOT, the indica-
tor also starts to flash.
If the cooling system overheats, the maximum engine
speed is limited.
Possible states
• The engine is cold
– The coolant temperature indicator
shows LOW.
• Engine warm – The coolant temperature indicator shows OK.
• Engine hot – The coolant temperature indicator shows HOT.
7.19 Fuel level display
I00207-01
The fuel level display consists of the fuel range display and a bar.
The higher the bar is filled, the more fuel is in the fuel tank
Info
Measurement of the fuel supply only becomes active after
reaching half of the fuel tank content. Up to half of the fuel
tank content, the fuel level display will be shown as full.
If the fuel level is getting low, the last segment flashes red
and the following warning LOW FUEL also appears.
The fuel level is displayed with a slight delay to prevent the
indicator from constantly moving while riding.
The fuel level display is not updated while the side stand is
folded out or the emergency off switch is switched off.
Once the side stand is folded up and the emergency OFF
switch is switched on, the fuel level display is next updated
after 2 minutes.
The fuel level display flashes if the combination instrument
does not receive a signal from the fuel level sensor.
7.20 Heated grip (optional)
I00208-10
The status of the grip heater is shown in area
1
of the display.
The grip heater can be configured in the Heated Grip menu.
