2-S6
F2880, F3680, RCK72-F36, RCK72R-F36, RCK60-F36, RCK60R-F36, WSM
TRANSMISSION
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts : See page G-8)
W1012736
Item N·m kgf·m ft-lbs
Holder shaft mounting screw 23.5 to 27.4 2.40 to 2.79 17.4 to 20.2
Oil strainer 98.1 to 137.2 10.0 to 14.0 72.4 to 101.2
ROPS mounting screw 123 to 147 12.6 to 14.9 90.8 to 108.4
Seat base mounting screw 17.7 to 20.5 1.8 to 2.1 13.1 to 15.1
Power steering hose mounting nut 24.6 to 29.4 2.5 to 3.0 18.1 to 21.6
Power steering pipe mounting nut 54.0 to 63.7 5.5 to 6.5 39.8 to 47.0
Delivery pipe mounting nut 39.3 to 47.0 4.0 to 5.0 28.9 to 36.1
Drive shaft mounting screw 27.5 to 29.4 2.8 to 3.0 20.3 to 21.6
Transmission mounting screw (M12) 62.8 to 72.5 6.4 to 7.4 46.3 to 53.5
Side frame mounting screw and nut 62.8 to 72.5 6.4 to 7.4 46.3 to 53.5
Front wheel mounting nut 39.3 to 44.1 4.0 to 4.5 29.0 to 32.5
PTO pipe mounting nut 54.0 to 63.7 5.5 to 6.5 39.8 to 47.0
HST mounting screw (M8) 23.6 to 27.4 2.4 to 2.8 17.4 to 20.2
HST mounting screw (M10) 39.3 to 44.1 4.0 to 4.5 29.0 to 32.5
Transmission case mounting screw and nut 39.3 to 44.1 4.0 to 4.5 29.0 to 32.5
Hydraulic cylinder mounting screw and nut 39.3 to 44.1 4.0 to 4.5 29.0 to 32.5
Front axle case mounting screw 39.3 to 44.1 4.0 to 4.5 29.0 to 32.5
Center section hex. socket screw 49.0 to 58.8 5.0 to 6.0 36.2 to 43.4
Valve plug 58.8 to 98.1 6.0 to 10.0 43.4 to 72.3
Differential bearing holder mounting screw 17.7 to 20.5 1.8 to 2.1 13.1 to 15.1
Spiral bevel gear UBS screw 29.5 to 34.3 3.0 to 3.5 21.7 to 25.3
