8-S1
F2880, F3680, RCK72-F36, RCK72R-F36, RCK60-F36, RCK60R-F36, WSM
ELECTRICAL SYSTEM
1. TROUBLESHOOTING
W1014322
BATTERY
W1013718
STARTING SYSTEM
W1013718
Symptom Probable Cause Solution
Reference
Page
All Electrical
Equipment Does Not
Operate
Battery discharged or defective Recharge or replace 8-S4
Battery positive cable disconnected or
improperly connected
Repair or replace 8-S4
Battery negative cable disconnected or
improperly connected
Repair or replace 8-S4
Slow blow fuse blown Replace G-34
Fuse Blows
Frequently
Short-circuited Repair or replace –
Battery Discharges
Too Quickly
Battery defective Recharge or replace 8-S4
Alternator defective Repair or replace 8-S11 to S12
Wiring harness disconnected or improperly
connected
Repair or replace –
Cooling fan belt slipping Adjust tension G-25
Starter Does Not Work Battery discharged or defective Recharge or replace 8-S4
Slow blow fuse blown Replace G-34
Brake switch defective Replace 8-S10
PTO switch defective Replace 8-S10
Seat switch defective Replace 8-S9
Controller defective Replace G-19, 6-S6
Wiring harness disconnected or improperly
connected
Repair or replace –
Starter defective Repair or replace 8-S19 to S21
Main switch defective Replace 8-S6 to S7
Glow Plug Does Not
Glow
Battery discharged or defective Recharge or replace 8-S4
Slow blow fuse blown Replace G-34
Wiring harness disconnected or improperly
connected
Repair or replace –
Glow plug defective Replace 8-S9
Main switch defective Replace 8-S6 to S7
Engine Does Not Stop
When Main Switch Is
Turned “OFF”
Position
Fuse blown Replace G-34
Wiring harness disconnected or improperly
connected
Repair or replace –
Main switch defective Replace 8-S6 to S7
Engine stop solenoid defective Replace 8-S11
Controller defective Replace G-19, 6-S6
Engine Does Not
Restart
Engine stop solenoid defective Replace 8-S11
Controller defective Replace G-19, 6-S6
To Next Page
