4-S2
F2880, F3680, RCK72-F36, RCK72R-F36, RCK60-F36, RCK60R-F36, WSM
BRAKES
2. SERVICING SPECIFICATIONS
W1013874
Item Factory Specification Allowable Limit
Brake Pedal Free Travel 20 mm
0.79 in.
20 to 30 mm
0.79 to 1.18 in.
Main Brake Pedal Force 373 to 411 N
38 to 42 kgf
84 to 92 lbs
–
Actuator and Bearing Holder Flatness – 0.30 mm
0.0118 in.
Actuator and Ball Height 22.89 to 22.99 mm
0.9012 to 0.9051 in.
22.40 mm
0.8819 in.
Brake Disc Thickness 3.3 to 3.5 mm
0.130 to 0.137 in.
3.0 mm
0.118 in.
Friction Plate Thickness 1.92 to 2.08 mm
0.0756 to 0.0818 in.
1.52 mm
0.0598 in.
To Next Page
