5-S1
F2880, F3680, RCK72-F36, RCK72R-F36, RCK60-F36, RCK60R-F36, WSM
REAR AXLE
1. TROUBLESHOOTING
W1014322
Symptom Probable Cause Solution
Reference
Page
Rear Wheels Wander
to Right of Left
Tire pressure uneven Adjust G-43
Improper toe-in adjustment (improper alignment) Adjust 5-S4
Clearance between rear axle case boss and rear
axle bracket (front, rear) excessive
Replace 5-S15
Rear axle rocking force too small Adjust 5-S4
Rear wheel sway excessive Replace –
Tie-rod end loose Tighten 5-S7
Air sucked in power steering circuit Bleed –
Rear Wheels Can Not
Be Driven
Rear wheel driving gears in rear axle gear case
broken
Replace 5-S9
Rear wheel drive shaft broken Replace 5-S6
Rear wheel drive gears in transmission broken Replace 2-S20
Rear differential gear broken Replace 5-S10 to
S11
Coupling displaced Reassemble 5-S6
Noise Gear backlash excessive Adjust or replace 5-S11
Oil insufficient Replenish G-7, 5-S5
Bearings damaged or broken Replace 5-S8 to S11
Gears damaged or broken Replace 5-S8 to S11
Bevel pinion shaft turning force improper Adjust 5-S13
To Next Page
