G-34
F2880, F3680, RCK72-F36, RCK72R-F36, RCK60-F36, RCK60R-F36, WSM
G GENERAL
[11] OTHERS
Bleeding Fuel System
CAUTION
• Do not bleed the fuel system when the engine is hot.
Air must removed :
1. When the fuel filter or lines are removed.
2. When tank is completely empty.
3. After the machine has not been used for a long period of time.
Bleeding procedure is as follows :
1. Fill the fuel tank with fuel.
2. Turn the key switch to the “ON” position.
3. Loosen the bleed screw (1).
When bubbles disappear from fuel coming out of the plug, tighten
the bleed screw.
W1051059
Replacing Fuse
1. The electrical system is protected from potential damage by
fuses.
A blown fuse indicates that there is an overload or short
somewhere in the electrical system.
2. If any of the fuses should blow, replace with a new one of the
same capacity.
■
• Before replacing a blown fuse, determine why the fuse blew
and make any necessary repairs. Failure to follow this
procedure may result in serious damage to the electrical
system.
■ Protected circuit
W1051895
Replacing Light Bulb
1. Head light
Take the bulb out of the light body and replace with a new one.
W1052077
Adjusting Lift Springs
1. In order to help improve traction, adjust the lift spring.
Refer to page 2-S16 (“TRANSMISSION” Section).
W1039531
(1) Bleed Screw
Fuse No. Capacity (A) Protected Circuit
(1) 5 ACC
(2) 10 Head Light, Fuel Pump
(3) 15 Working Light
(4) Slow Blow Fuse 50
Check circuit against wrong
battery connection
Light Capacity
Head light 15 W
To Next Page
