UDS2100 Device Server User Guide 18
4: Using DeviceInstaller
This chapter covers the steps for getting the UDS2100 device server online and
for viewing its current configuration.
Note: DeviceInstaller is a free utility program provided by Lantronix that
discovers, configures, upgrades, and manages Lantronix Device Servers.
It can be downloaded from the Lantronix website at
www.lantronix.com/support/downloads
.
For instructions on using DeviceInstaller to configure the IP address and
related settings or for more advanced features, see the DeviceInstaller
Online Help.
Installing DeviceInstaller
To install DeviceInstaller:
1. Download the latest version of DeviceInstaller from
http://www.lantronix.com/support/downloads
.
2. Run the executable to start the installation process.
3. Respond to the installation wizard prompts. (If prompted to select an
installation type, select Typical).
Assigning an IP Address
The unit’s IP address must be configured before it can work correctly on a
network. The unit’s IP address is normally set to 0.0.0.0 at the factory. The
hardware address is on the product label. The unit is DHCP enabled as the
default.
To assign an IP address manually:
1. Click Start

Programs

Lantronix

DeviceInstaller

DeviceInstaller. If
your PC has more than one network adapter, a message displays. Select an
adapter and click OK.
Note: If the unit already has an IP address (e.g., DHCP has assigned
an IP address), click the Search icon
and select the unit from the
list of Lantronix device servers on the local network.
2. Click the Assign IP icon .
3. If prompted, enter the hardware address (on the product label) and click
Next.

Lantronix UDS2100 Specifications

General

Isolation	1.5 kV
Certification	FCC, C/UL, CSA, VCCI, CE, TUV, CTick
Serial interface type	RS-232/422/485
Serial ports quantity	2
Ethernet LAN data rates	10, 100 Mbit/s
Electrostatic Discharge (ESD) protection	15 kV
USB 2.0 ports quantity	0
Supported network protocols	ARP, UDP, TCP, ICMP, Telnet, TFTP, AutoIP, DHCP, HTTP, SNMP TCP, UDP, Telnet, TFTP, RFC2217
Built-in processor	Lantronix DSTNI-EX
Processor frequency	48 MHz
Compatible operating systems	Windows 98/ME/NT/2000/XP
Flash memory	2 MB
RAM capacity	0.256 MB
LED indicators	LAN, Y
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	10 - 90 %
Input voltage	9 - 30 V

Weight and Dimensions

Weight	400 g
Dimensions (WxDxH)	72 x 23 x 95 mm
