9: Setup Mode: Advanced Settings
UDS2100 Device Server User Guide 64
Disable Web Setup
The Y (Yes) option disables configuration using the Web Manager. This setting
defaults to the N (No) option.
Disable Web Setup (N) ? _
Disable ECHO Ports
This setting controls whether port 7 echoes characters it receives. The default
setting is Y (Yes), which disables ECHO ports.
Disable ECHO ports (Y) ? _
Enable Enhanced Password
This setting defaults to the N (No) option, which allows you to set a 4-character
password that protects Setup Mode by means of Telnet and web pages. The Y
(Yes) option allows you to set an extended security password of 16-characters
for protecting Telnet and Web Page access.
Enable Enhanced Password (N) ? _
Default Settings (Option 7)
Select 7 to reset the unit’s Channel 1 & 2 configuration and expert settings to the
default settings. The server configuration settings for IP address, gateway IP
address, and netmask remain unchanged. The specific settings that this option
changes are listed below:
Channel 1 & 2 Configuration Defaults
Baudrate
9600
I/F Mode
4C (1 stop bit, no parity, 8 bit, RS-232C)
TCP port number
10001 on Channel 1
10002 on Channel 2
Connect Mode
C0 (always accept incoming connection; no active
connection startup)
Hostlist retry counter
3
Hostlist retry timeout
250 (msec)
Start Character
0x0D (CR)
All other parameters
0
Expert Settings Defaults
TCP Keepalive time in s
45
ARP Cache timeout in s
600

Lantronix UDS2100 Specifications

General

Isolation	1.5 kV
Certification	FCC, C/UL, CSA, VCCI, CE, TUV, CTick
Serial interface type	RS-232/422/485
Serial ports quantity	2
Ethernet LAN data rates	10, 100 Mbit/s
Electrostatic Discharge (ESD) protection	15 kV
USB 2.0 ports quantity	0
Supported network protocols	ARP, UDP, TCP, ICMP, Telnet, TFTP, AutoIP, DHCP, HTTP, SNMP TCP, UDP, Telnet, TFTP, RFC2217
Built-in processor	Lantronix DSTNI-EX
Processor frequency	48 MHz
Compatible operating systems	Windows 98/ME/NT/2000/XP
Flash memory	2 MB
RAM capacity	0.256 MB
LED indicators	LAN, Y
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	10 - 90 %
Input voltage	9 - 30 V

Weight and Dimensions

Weight	400 g
Dimensions (WxDxH)	72 x 23 x 95 mm
