Lantronix UDS2100 User Manual

5: Configuration Using Web Manager
UDS2100 Device Server User Guide 28
Figure 5-4. Server Settings
To configure the UDS2100 device server settings:
1. On the main menu, click Server.
2. Configure or modify the following fields:
Server Configuration
Enhanced Password
Select whether to enable advanced password:
 Enable: selecting this option enables advanced
password creation, allowing you to create passwords up
to 16 bytes in length.
 Disable: selecting this option disables advanced
password creation, allowing you to create basic
passwords up to 4 bytes in length.
Telnet/Web Manager
Password
Enter the password required for Telnet configuration and Web
Manager access.
Retype Password
Re-enter the password required for Telnet configuration and
Web Manager access.
Advanced
ARP Cache Timeout
When the unit communicates with another device on the

Lantronix UDS2100 Specifications

General

Isolation	1.5 kV
Certification	FCC, C/UL, CSA, VCCI, CE, TUV, CTick
Serial interface type	RS-232/422/485
Serial ports quantity	2
Ethernet LAN data rates	10, 100 Mbit/s
Electrostatic Discharge (ESD) protection	15 kV
USB 2.0 ports quantity	0
Supported network protocols	ARP, UDP, TCP, ICMP, Telnet, TFTP, AutoIP, DHCP, HTTP, SNMP TCP, UDP, Telnet, TFTP, RFC2217
Built-in processor	Lantronix DSTNI-EX
Processor frequency	48 MHz
Compatible operating systems	Windows 98/ME/NT/2000/XP
Flash memory	2 MB
RAM capacity	0.256 MB
LED indicators	LAN, Y
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	10 - 90 %
Input voltage	9 - 30 V

Weight and Dimensions

Weight	400 g
Dimensions (WxDxH)	72 x 23 x 95 mm
