8: Setup Mode: Channel Configuration
UDS2100 Device Server User Guide 57
Table 8-10. Flush Mode Options
Function
7
6
5
4
3
2
1
0
Input Buffer (Serial to Network)
Clear with a connection initiated from the device to the network
1
Clear with a connection initiated from the network to the device
1
Clear when the network connection to or from the device is disconnected
1
Output Buffer (Network to Serial)
Clear with a connection initiated from the device to the network
1
Clear with a connection initiated from the network to the device
1
Clear when the network connection to or from the device is disconnected
1
Alternate Packing Algorithm (Pack Control)
Enable
1
Pack Control
The packing algorithms define how and when packets are sent to the network.
The standard algorithm is optimized for applications in which the unit is used in a
local environment, allowing for very small delays for single characters, while
keeping the packet count low. The alternate packing algorithm minimizes the
packet count on the network and is especially useful in applications in a routed
Wide Area Network (WAN). Adjusting parameters in this mode can economize
the network data stream.
Pack control settings are enabled in Flush Mode. Set this value to 00 if you do
not need specific functions.
Note: All bit positions in the table that are blank represent “don’t care” bits
for that particular option, which can be set to either a 0 or 1 value.
Table 8-11. Pack Control Options
Option
7
6
5
4
3
2
1
0
Packing Interval
Interval: 12 msec
0
0
Interval: 52 msec
0
1
Interval: 250 msec
1
0
Interval: 5 sec
1
1
Trailing Characters
None
0
0
One
0
1
Two
1
0
2-Byte Send Character Sequence
1
