Table C-1. UDS2100 Technical Specifications
Category
Description
CPU
Lantronix DSTNI-EX 48 MHz clock
Internal CPU Memory
256 KB zero wait state SRAM
Flash
2 MB Flash
EEPROM
2 or 4 KB EEPROM
Serial Interface
2 DB9M DTE serial ports
Software-selectable baud rate from 300 to 921 KBaud (when High
Performance is selected)
Software-selectable RS232, RS422 or RS485 (2 and 4 wire support)
Serial Line Formats
Characters: 7 or 8 data bits
Stop bits: 1 or 2
Parity: odd, even, none
Modem Control
Modem Control In, DTR
Flow Control
Hardware: CTS/RTS
Software: XON/XOFF
Power Input
9-30n VDC on barrel connector (1.8W maximum consumption)
Network Interface
1 RJ45 10Base-T/100Base-TX Ethernet port
Software selectable Ethernet speed 10/100/Auto
Software selectable Half/Full/Auto duplex
Dimensions
Height: 2.3 cm (0.9 in)
Width: 7.3 cm (2. 9 in)
Length : 9.5 cm ( 3.75 in)
Weight
0.26 kg ( 0.6 lb)
Temperature
Operating range: 0° to 60° C (32° to 140° F)
Note: Operating range for UDS2100-IAP only: -40° to 70° C (-40° to 158° F)
Storage -40° to 85° C (-40 to 185° F)
Relative Humidity
Operating 10% to 90% non-condensing, 40% to 60% recommended
Storage 10% to 90% non-condensing
Case
Metal enclosure with integrated wall mounts
Optional 35 mm Din Rail mount available
Protocols Supported
ARP, UDP/IP, TCP/IP, Telnet, ICMP, SNMP, DHCP, BOOTP, TFTP, and
HTTP
C: Technical Specifications

Lantronix UDS2100 Specifications

General

Isolation	1.5 kV
Certification	FCC, C/UL, CSA, VCCI, CE, TUV, CTick
Serial interface type	RS-232/422/485
Serial ports quantity	2
Ethernet LAN data rates	10, 100 Mbit/s
Electrostatic Discharge (ESD) protection	15 kV
USB 2.0 ports quantity	0
Supported network protocols	ARP, UDP, TCP, ICMP, Telnet, TFTP, AutoIP, DHCP, HTTP, SNMP TCP, UDP, Telnet, TFTP, RFC2217
Built-in processor	Lantronix DSTNI-EX
Processor frequency	48 MHz
Compatible operating systems	Windows 98/ME/NT/2000/XP
Flash memory	2 MB
RAM capacity	0.256 MB
LED indicators	LAN, Y
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	10 - 90 %
Input voltage	9 - 30 V

Weight and Dimensions

Weight	400 g
Dimensions (WxDxH)	72 x 23 x 95 mm
