5: Configuration Using Web Manager
UDS2100 Device Server User Guide 26
To assign an IP address automatically:
1. On the main menu, click Network.
2. Select Obtain IP address automatically.
3. Enter the following (as necessary):
Select Enable to permit the Bootstrap Protocol (BOOTP) server to
assign the IP address from a pool of addresses automatically.
Enable is the default.
Select Enable to permit the Dynamic Host Configuration Protocol
(DHCP) to assign a leased IP address to the UDS2100 unit
automatically. Enable is the default.
Select Enable to permit the UDS2100 to generate an IP in the
169.254.x.x address range with a Class B subnet. Enable is the
default.
Enter the name of the host on the network providing the IP address.
Note: Disabling BOOTP, DHCP, and AutoIP (all three checkboxes) is not
advised as the only available IP assignment method will then be ARP or
serial port.
4. When you are finished, click the OK button.
5. On the main menu, click Apply Settings.
Static IP Address Configuration
You can manually assign an IP address to the unit and enter related network
settings.
To assign an IP address manually:
1. On the main menu, click Network.
2. Select Use the following IP configuration.
3. Enter the following (as necessary):
If DHCP is not used to assign IP addresses, enter it manually
in decimal-dot notation. The IP address must be set to a
unique value in the network.
A subnet mask defines the number of bits taken from the IP
address that are assigned for the host part.
The gateway address, or router, allows communication to
other LAN segments. The gateway address should be the IP
address of the router connected to the same LAN segment as
the unit. The gateway address must be within the local
network.
The DNS server allows the name of a remote machine to be
resolved automatically. Enter the IP address of the DNS
server. If the device is DHCP enabled, the DHCP server
provides the DNS server IP address, which will override this
To Next Page
