6: Configuration via Telnet or Serial Port (Setup Mode)
UDS2100 Device Server User Guide 40
Windows: telnet x.x.x.x 9999
UNIX: telnet x.x.x.x:9999
2. Click OK. The following information displays.
Figure 6-1. MAC Address
*** Lantronix UDS2100 Device Server ***
MAC address 00204AC10205
Software version V6.11.0.0 (150508)
Press Enter for Setup Mode
3. To enter Setup Mode, press Enter within 5 seconds. The configuration
settings display, followed by the Change Setup menu.
Figure 6-2. Setup Menu Options
Change Setup:
0 Server
1 Channel 1
2 Channel 2
5 Expert
6 Security
7 Defaults
8 Exit without save
9 Save and exit Your choice? _
4. Select an option on the menu by entering the number of the option in the
Your choice? field and pressing Enter.
5. To enter a value for a parameter, type the value and press Enter, or to
confirm a current value, just press Enter.
6. When you are finished, save the new configuration (option 9). The unit
reboots.
Serial Port Connection
To configure the unit through a serial connection:
1. Connect a console terminal or PC running a terminal emulation program to
your unit's serial port. The default serial port settings are 9600 baud, 8 bits,
no parity, 1-stop bit, no-flow control.
2. Reset the UDS2100 unit by cycling the unit's power (turning the power off
and back on). Immediately upon resetting the device, enter three lowercase x
characters (xxx).
Note: The easiest way to enter Setup Mode is to hold down the x key
at the terminal (or emulation) while resetting the unit. You must do
this within three seconds of resetting the UDS2100.
At this point, the screen display is the same as when you use a Telnet
connection. To continue, go to step 3 in Telnet Connection, above.
