5: Configuration Using Web Manager
UDS2100 Device Server User Guide 37
Use Broadcast
Select to broadcast the UDP datagram. Datagrams of type 01
can be sent as a broadcast by enabling this option. The
default is not to broadcast.
Note: Datagrams are sent as subnet-directed broadcasts.
Device Address Table
The table is enabled when Datagram Type is set to FD. Enter
values between 1 and 255 to identify units on the local
network of device servers.
Note: Lantronix Tech Support supports Datagram type 01.
Datagram Type FD is for OEM use.
3. When you are finished, click the OK button.
4. On the main menu, click Apply Settings.
Apply Settings
1. To save and apply the configuration changes to the device server, click the
Apply Settings button.
Note: Clicking OK on each page does not change the configuration on the
device. Clicking the OK button tells the UDS2100 what changes to use; the
Apply Settings button makes the changes permanent and reboots the
UDS2100.
Apply Defaults
1. Click the Apply Defaults button to set the device server back to the default
settings. For details see Default Settings.
2. Click Yes to set factory settings, or click No to cancel.

Lantronix UDS2100 Specifications

General

Isolation	1.5 kV
Certification	FCC, C/UL, CSA, VCCI, CE, TUV, CTick
Serial interface type	RS-232/422/485
Serial ports quantity	2
Ethernet LAN data rates	10, 100 Mbit/s
Electrostatic Discharge (ESD) protection	15 kV
USB 2.0 ports quantity	0
Supported network protocols	ARP, UDP, TCP, ICMP, Telnet, TFTP, AutoIP, DHCP, HTTP, SNMP TCP, UDP, Telnet, TFTP, RFC2217
Built-in processor	Lantronix DSTNI-EX
Processor frequency	48 MHz
Compatible operating systems	Windows 98/ME/NT/2000/XP
Flash memory	2 MB
RAM capacity	0.256 MB
LED indicators	LAN, Y
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	10 - 90 %
Input voltage	9 - 30 V

Weight and Dimensions

Weight	400 g
Dimensions (WxDxH)	72 x 23 x 95 mm
