8: Setup Mode: Channel Configuration
UDS2100 Device Server User Guide 48
Table 8-5. Connect Mode Options
Connect Mode Option
7
6
5
4
3
2
1
0
a) Incoming Connection
Never accept incoming
0
0
0
Accept with active Modem Control In
0
1
0
Always Accept
1
1
0
b) Response
Nothing (quiet)
0
Character response (C=connect,
D=disconnect, N=unreachable)
1
c) Active Startup
No active startup
0
0
0
0
With any character
0
0
0
1
With active Modem Control In
0
0
1
0
With a specific start character
0
0
1
1
Manual connection
0
1
0
0
Autostart
0
1
0
1
Hostlist
0
0
1
0
d) Datagram Type
Directed UDP
1
1
0
0
e) Modem Mode
No Echo
0
0
1
1
Data Echo & Modem Response
(Numeric)
0 1 1 1 1
Data Echo & Modem Response
(Verbose)
0 1 1 1 0
Modem Response Only (Numeric)
0
0
1
1
1
1
Modem Response Only (Verbose)
0
0
1
1
1
0
a) Incoming Connection
Never Accept Incoming
Rejects all external connection attempts.
Accept with active
Modem Control in
Accepts external connection requests only when Modem
Control In input is asserted. Cannot be used with Modem
Mode.
Always Accept
Accepts any incoming connection when a connection is not
already established. Default setting.

Lantronix UDS2100 Specifications

General

Isolation	1.5 kV
Certification	FCC, C/UL, CSA, VCCI, CE, TUV, CTick
Serial interface type	RS-232/422/485
Serial ports quantity	2
Ethernet LAN data rates	10, 100 Mbit/s
Electrostatic Discharge (ESD) protection	15 kV
USB 2.0 ports quantity	0
Supported network protocols	ARP, UDP, TCP, ICMP, Telnet, TFTP, AutoIP, DHCP, HTTP, SNMP TCP, UDP, Telnet, TFTP, RFC2217
Built-in processor	Lantronix DSTNI-EX
Processor frequency	48 MHz
Compatible operating systems	Windows 98/ME/NT/2000/XP
Flash memory	2 MB
RAM capacity	0.256 MB
LED indicators	LAN, Y
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	10 - 90 %
Input voltage	9 - 30 V

Weight and Dimensions

Weight	400 g
Dimensions (WxDxH)	72 x 23 x 95 mm
