5: Configuration Using Web Manager
UDS2100 Device Server User Guide 27
configured value.
Note: This setting is applicable only in Manual Connection
mode.
4. When you are finished, click the OK button.
5. On the main menu, click Apply Settings.
Ethernet Configuration
You must specify the speed and direction of data transmission.
To specify how data will be transmitted:
1. On the main menu, click Network.
2. Enter the following (as necessary):
Auto Negotiate
With this option, the Ethernet port auto-negotiates the speed and
duplex with the hardware endpoint to which it is connected. This is the
default.
If this option is not selected, complete the fields that become available:
 Speed: The speed of data transmission. The default setting is 100
Mbps.
 Duplex: The direction of data transmission. The default setting is
Full.
3. When you are finished, click the OK button.
4. On the main menu, click Apply Settings.
Server Configuration
The unit’s server values display when you select Server from the main menu.
The following sections describe the configurable parameters on the Server
Settings page.

Lantronix UDS2100 Specifications

General

Isolation	1.5 kV
Certification	FCC, C/UL, CSA, VCCI, CE, TUV, CTick
Serial interface type	RS-232/422/485
Serial ports quantity	2
Ethernet LAN data rates	10, 100 Mbit/s
Electrostatic Discharge (ESD) protection	15 kV
USB 2.0 ports quantity	0
Supported network protocols	ARP, UDP, TCP, ICMP, Telnet, TFTP, AutoIP, DHCP, HTTP, SNMP TCP, UDP, Telnet, TFTP, RFC2217
Built-in processor	Lantronix DSTNI-EX
Processor frequency	48 MHz
Compatible operating systems	Windows 98/ME/NT/2000/XP
Flash memory	2 MB
RAM capacity	0.256 MB
LED indicators	LAN, Y
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	0 - 60 °C
Operating relative humidity (H-H)	10 - 90 %
Input voltage	9 - 30 V

Weight and Dimensions

Weight	400 g
Dimensions (WxDxH)	72 x 23 x 95 mm
