Loading...How to fix 'Wrong Password' error when upgrading Lantronix UDS2100 Server firmware?
To resolve the "Wrong Password" error when upgrading the firmware on your Lantronix Server using DeviceInstaller, download the correct firmware file from the Lantronix website, as the file you're currently trying to load is likely the incorrect one for the UDS.
Why can't I connect to my Lantronix UDS2100, even with correct settings?
The most likely reason for connection issues with the Lantronix Server is a mismatch in serial settings. Ensure that the serial settings for both the serial device and the device server are identical. The default serial settings for the device server are RS-232, 9600 baud, 8 character bits, no parity, 1 stop bit, and no flow control.
What to do if my computer cannot connect to port 30718 on Lantronix UDS2100?
To resolve the issue of your computer being unable to connect to port 30718 (77FEh) on the Lantronix Server, ensure that port 30718 (77FEh) is not blocked by any router on your network. Also, verify that port 77FEh is not disabled within the Security settings of the device server.
How to connect to the correct socket of Lantronix UDS2100?
If you are sure that the serial port setting is correct, then you may not be connecting to the correct socket of the Lantronix Server. Use the Connect Mode option C0 for making a connection to the UDS from the network. Use Connect Mode option C1 or C5 for a connection to the network from the UDS.
What to do if IP address is not on logical subnet of Lantronix UDS2100?
To address the issue where the IP address you're assigning isn't on your logical subnet for the Lantronix Server, ensure your PC has an IP address within the same logical subnet you're attempting to assign to the device server.
How to enter the Ethernet address correctly with the ARP command for Lantronix UDS2100?
To correct the issue of entering the Ethernet address incorrectly with the ARP command for your Lantronix Server, confirm that the Ethernet address you entered is correct. The Ethernet address may only include numbers 0-9 and letters A-F. In Windows and usually in Unix, the segments of the Ethernet address are separated by dashes. In some forms of Unix, the Ethernet address is segmented with colons.
How to resolve insufficient rights to use command on Lantronix UDS2100 Server?
To resolve the issue of insufficient user rights on your PC to use a command on the Lantronix Server, have someone from your IT department log you in with sufficient rights.
Why can I ping Lantronix Server but not Telnet to port 9999?
If you can ping the Lantronix Server but can't Telnet to it on port 9999, there might be an IP address conflict on your network, you might not be Telneting to port 9999, or the Telnet configuration port (9999) might be disabled in the device server's security settings. To resolve this, turn off the device server, then open the command prompt on your computer and enter these commands: * `ARP -D X.X.X.X` (replace `X.X.X.X` with the device server's IP address) * `PING X.X.X.X` (replace `X.X.X.X` with the device server's IP address) If you get a response after the ping, there is a duplicate IP address on the network. If there is no response, use the serial port to check if Telnet is disabled.
What to do if Lantronix UDS2100 is not communicating with the connected device?
If the Lantronix Server appears correctly set up but isn't communicating with your attached device across the network, ensure your serial port settings are correct and that you are connecting to the correct socket on the device server. Also, verify the device server is properly set up to make a solid socket connection to the network. * Use Connect Mode option `C0` for making a connection to the UDS from the network. * Use Connect Mode option `C1` or `C5` for a connection to the network from the UDS.
How to fix 'No Connection With The Device Server' message on Lantronix Server?
If you encounter the "No Connection With The Device Server" message when trying to connect to the Web Manager within the Lantronix Server, it means your computer can't connect to port 30718 (77FEh) on the device server. Ensure that port 30718 (77FEh) isn't blocked by any router on your network and that port 77FEh isn't disabled within the Security settings of the device server.
General| Isolation | 1.5 kV |
|---|---|
| Certification | FCC, C/UL, CSA, VCCI, CE, TUV, CTick |
| Serial interface type | RS-232/422/485 |
| Serial ports quantity | 2 |
| Ethernet LAN data rates | 10, 100 Mbit/s |
| Electrostatic Discharge (ESD) protection | 15 kV |
| USB 2.0 ports quantity | 0 |
| Supported network protocols | ARP, UDP, TCP, ICMP, Telnet, TFTP, AutoIP, DHCP, HTTP, SNMP TCP, UDP, Telnet, TFTP, RFC2217 |
| Built-in processor | Lantronix DSTNI-EX |
| Processor frequency | 48 MHz |
| Compatible operating systems | Windows 98/ME/NT/2000/XP |
| Flash memory | 2 MB |
| RAM capacity | 0.256 MB |
| LED indicators | LAN, Y |
| Storage temperature (T-T) | -40 - 85 °C |
| Operating temperature (T-T) | 0 - 60 °C |
| Operating relative humidity (H-H) | 10 - 90 % |
| Input voltage | 9 - 30 V |
Weight and Dimensions| Weight | 400 g |
|---|---|
| Dimensions (WxDxH) | 72 x 23 x 95 mm |
Manual process to assign an IP via DeviceInstaller.
Steps to locate and select the UDS2100 in DeviceInstaller.
How to check the unit's current settings in DeviceInstaller.
Assigning IP address and network settings using a serial connection.
Settings for network parameters like IP, Subnet Mask, and Gateway.
Explains DHCP, BOOTP, AutoIP for automatic IP assignment.
Manual configuration of IP, Subnet Mask, Gateway, and DNS.
General server-side settings for the UDS2100.
Defines serial port behavior for network communication.
Configuration of baud rate, data bits, parity, etc.
TCP specific connection parameters for channels.
UDP specific connection parameters for channels.
How to save and apply configuration changes to the device.
How to reset settings to factory defaults.
How to enter Setup Mode via Telnet or serial port.
Steps to access Setup Mode via a serial connection.
Basic network parameters like IP, Gateway, and Netmask.
Manual IP assignment and DHCP/BOOTP/AutoIP options.
Configuration of the default gateway address.
Defines the subnet mask for IP addressing.
Configuration of the DNS server address.
Setting a password for setup access.
Configuring serial port settings for Channel 1.
Setting serial interface parameters (RS232, RS485).
Configuration of flow control settings for serial ports.
Setting the TCP port number for connections.
Defining how connections are made and handled.
Configuring the unit for modem emulation.
Setting the destination IP for outgoing connections.
Setting the destination port for outgoing connections.
Setting a password for serial port access.
Advanced configuration options not available via Web Manager.
Security-related configuration options.
