8.2 PROFINET
This chapter contains informaon on the following chapters:
4Commissioning ^ 72
4Basic seng and opons ^ 74
4Process data transfer ^ 75
4Parameter data transfer ^ 76
4Monitoring ^ 77
4Diagnoscs ^ 78
PROFINET® (Process Field Network) is a real-me capable network based on Ethernet.
•
PROFINET® is a registered trademark and patented technology licensed by the PROFIBUS &
PROFINET Internaonal (PI) user organizaon.
•
Detailed informaon on PROFINET can be found on the web page of the user organizaon:
hp://www.probus.com
•
PROFINET transmits, between the IO-Devices and a IO-Controller (PLC), parameter data,
conguraon data, diagnosc data, alarm messages, and process data.
•
The data is transmied as a funcon of its me-crical behavior via corresponding
communicaon channels.
•
The device is implemented as a PROFINET-Device in a PROFINET RT network.
•
The PROFINET connecons are realized as standard RJ45 sockets.
•
Further informaon about the dimensioning of a PROFINET network can be found in the
conguraon document.
Precondions
•
The device is equipped with the "PROFINET" network opon via slot 1. 4Features ^ 12
PROFINET connecon
•
PROFINET is connected via the RJ45 sockets. X2x6 and X2x7.
•
An Ethernet cable CAT 5/5e can be used for the connecon to the network, 2-pair with
AWG22 (American Wire Gauge) or 4-pair with AWG22/24.
More informaon about connecons can be found on the Internet:
www.probus.org à PROFINET Cabling and Interconnecon Technology
Conguring the network
PROFINET
70
