Lenze C520 User Manual

Address Name / seng range / [default seng] Informaon
0x2388 PROFINET status
•
Read only
Bit coded display of the current Bus status.
Bit 0 Inialized
Bit 1 Online
Bit 2 Connected
Bit 3 IP address error The IP address is invalid. Valid IP addresses are dened according to RFC
3330.
Bit 4 Hardware fault
Bit 6 Watchdog elapsed
Bit 7 Protocol error
Bit 8 PROFINET stack ok
Bit 9 PROFINET stack not congured
Bit 10 Ethernet controller fault
Bit 11 UDP stack fault
0x2389:001 PROFINET error: Error 1
•
Read only
The parameter currently contains the error detected on the network.
•
The error values may occur in combinaon with the error values from
parameter 0x2389:002.
0 No error
1 Reserved
2 Unit ID unknown
3 Max. units exceeded
4 Invalid size
5 Unit type unknown
6 Runme plug error
7 Invalid argument
8 Service pending
9 Stack not ready
10 Command unknown
11 Invalid address descriptor
0x2389:002 PROFINET error: Error 2
•
Read only
The parameter currently contains the error detected on the network.
•
The error values may occur in combinaon with the error values from
parameter 0x2389:001.
Bit 7 IP address error The IP address is invalid. Valid IP addresses are dened according to RFC
3330.
Bit 8 Staon name problem The staon name must be assigned according to the PROFINET
specicaon.
Bit 9 DataExch le PROFINET communicaon is connuously interrupted in the
"Data_Exchange" state, e. g. by cable break.
•
PROFINET communicaon changes to the "No_Data_Exchange" state.
•
When the watchdog monitoring me specied by the IO Controller
has elapsed, the response set in 0x2859:001 is triggered in the device.
Bit 10 Stack boot error
Bit 11 Stack online error
Bit 12 Stack state error
Bit 13 Stack revision error
Bit 14 Inializaon problem The stack cannot be iniated with the user specicaons. A reason
might be, e. g., a staon name that does not correspond to the
PROFINET specicaon.
Bit 15 Stack init error
Conguring the network
PROFINET
Diagnoscs
79
