Function library
Configuration of analog and digital setpoints and actual values
7−43
L
EDB82MV752 EN 5.2
7.6.5 Setpoints via fixed setpoints (JOG)
Description
You can store up to three fixed setpoints per parameter set and retrieve them using digital input
signals.
At operation with application I/O 7 fixed setpoints are available per parameter set.
Codes for parameter setting
Code Possible settings IMPORTANT
No. Name Lenze Selection
C0037 JOG1 20.00 −650.00 {0.02 Hz} 650.00
JOG = fixed setpoint
Additional fixed setpoints ð C0440
7−43
C0038 JOG2 30.00 −650.00 {0.02 Hz} 650.00
C0039 JOG3 40.00 −650.00 {0.02 Hz} 650.00
C0440
(A)
Additional JOG
values
−650.00 {0.02 Hz} 650.00 JOG = fixed setpoint
Activation via configuration in C0410
7−43
1 JOG 1 20.00 C04401/1 and C0037 are the same
2 JOG 2 30.00 C04401/2 and C0038 are the same
3 JOG 3 40.00 C04401/3 and C0039 are the same
4 JOG 4 15.00
5 JOG 5 25.00
6 JOG 6 35.00
7 JOG 7 45.00
Activation
Operation without application I/O
The signal NSET1−JOG1/3 must be combined with a digital input signal under C0410/1.
The signal NSET1−JOG2/3 must be combined with a digital input signal under C0410/2.
Active setpoint Level at
NSET1−JOG1/3 NSET1−JOG2/3
other setpoint source LOW LOW
JOG 1 HIGH LOW
JOG 2 LOW HIGH
JOG 3 HIGH HIGH
) Note!
In addition to the free configuration under C0410 you can also use the fixed
assignment under C0007 to combine the function with digital inputs.
