Function library
Display of operating data, diagnostics
7−89
L
EDB82MV752 EN 5.2
7.14.2 Diagnostics
Description
Display codes for diagnostics
Codes for parameter setting
Code Possible settings IMPORTANT
No. Name Lenze Selection
C0093* Controller type xxxy Only display
xxx = Power taken from nameplate (e.
g. 551 = 550 W)
y = Voltage class (2 = 240 V, 4 = 400 V)
C0099* Software version x.y Only display
x = Main version, y = Index
C0161* Active error
Display history buffer contents
Keypad: three−digit, alpha numerical
fault detection
9371BB keypad: LECOM fault number
8−1
C0162* Last fault
C0163* Last but one fault
C0164* Last but two fault
C0168* Actual fault History buffer displays "active error"
Keypad: three−digit, alpha numerical
fault detection
9371BB keypad: LECOM fault number
8−1
C0179* Power−on time {h} Only display
Total time mains on
C0183* Diagnostics
0 No fault
Only display
102 TRIP active
104 Message "Overvoltage (OU)" or "Undervoltage
(
LU)" active
142 Pulse inhibit
151 Quick stop active
161 DC−injection brake active
250 Warning active
C0200* Software ID
Read only on PC
x = main version, y = subversion
82S8212V_xy000 8200 vector 0.25 ... 11 kW
82S8212V_xy010 8200 vector 15 ... 90 kW
C0201* Software creation
date
Read only on PC
C0202* Software ID Output in keypad as string in four parts at four characters
each
Read only in keypad
1 82S8
2 212 V
3 _xy0 x = main version, y = subversion
4 zz 00 = 8200 vector 0.25 ... 11 kW
10 = 8200 vector 15 ... 90 kW
C0304
Service codes Modifications only by Lenze Service!
...
C0309
C0372* Function module
identification
0 No function module
Only display
1 Standard I/O or AS−i
2 System bus (CAN)
6 Other function module on FIF
e.g. application I/O, INTERBUS, ...
10 No valid recognition
C0518
Service codes Modifications only by Lenze Service!
C0519
C0520
