Commissioning
Selection of the correct control mode
5−4
L
EDB82MV752 EN 5.2
5.3 Selection of the correct control mode
The following table helps you to find the correct control mode for standard applications. You can
choose between V/f characteristic control, vector control and sensor torque control:
V/f characteristic control is the classic control mode for standard applications.
The vector control provides better control features than the V/f characteristic control because of:
a higher torque over the whole speed range
higher speed accuracy and smooth running features
higher efficiency
V/f characteristic control
Vector control
Tip!
The parameters for the corresponding control mode are to be set as follows:
for linear V/f characteristic control in menu USEr
for square−law V/f characteristic control, vector control or sensorless torque in menu ALL
