Parameter setting
With communication module LECOM−A (RS232)
6−9
L
EDB82MV752 EN 5.2
6.3 Parameter setting using the LECOM−A(RS232) communication
module
The LECOM−A (RS232) communication module connects the controller to a host (e.g. PC) via the
RS232 interface.
You need the following accessory components to use the communication module:
Parameterisation software Global Drive Control easy (GDC easy)"
PC system cable
Connecting cable
6.3.1 Technical data
6.3.1.1 General data/operating conditions
Communication module type E82ZBL
Communication medium RS232 (LECOM−A)
Communication protocol LECOM−A/B V2.0
Character format 7E1: 7 bits ASCII, 1 stop bit, 1 start bit, 1 parity bit (even)
Baud rate [Bit/s] 1200, 2400, 4800, 9600, 19200
LECOM−A node Slave
Network topology Point−to−point
Max. number of nodes 1
Max. cable length 15 m
Communication time See table
PC connection 9−pole Sub−D socket
DC voltage supply Internal
Insulation voltage to reference
earth/PE
50 V AC
Type of protection
EN60529 IP20
outside the wire range of the terminals
on the motor side
NEMA 250 Protection against accidental contact to
type 1
Climatic conditions
Permissible
Temperature ranges
Storage IEC/EN 60721−3−1 1K3 (−25 °C...+60 °C)
Transport IEC/EN 60721−3−2 2K3 (−25 °C...+70 °C)
Operation IEC/EN 60721−3−3 3K3 (0 °C...+55 °C)
Dimensions (L x B x H) 75 mm x 62 mm x 23 mm
