Appendix
Signal flow charts − Standard I/O
14−1
L EDB82MV752 EN 5.2
14 Appendix
14.1 Signal flow diagrams
How to read the signal flow diagrams
Symbol Meaning
Signal combination in the Lenze setting
Fixed signal combination
Analog input, can be freely connected with an analog output with the same identification
Analog output
Analog input to be used to connect the motor potentiometer output
Motor potentiometer output
Digital input, can be freely connected with a digital output with the same identification
Digital output
