7.10.2 Free configuration of analog outputs
Description
 The analog outputs (X3/62, X3/63) and the frequency output (X3/A4) can be freely assigned to
internal analog process signals or monitoring signals. The controller outputs a voltage
proportional to the internal signal at the analog outputs.
 Currents can also be output when using the application I/O.
– Range: 0 ... 20 mA, as of software version 1.1 also 4 ... 20 mA
– Setting via jumper at module and C0424
 A signal source can be assigned to several targets.
) Note!
Use C0111 to permanently assign the analog output X3/62 to some internal signal
sources. C0419/1 is automatically adapted.
Codes for parameter setting
Code Possible settings IMPORTANT
No. Name Lenze Selection
C0419

Free configuration
of analog outputs
Output of analog signals to terminal
 7−59
1 X3/62 (AOUT1−IN) 0 Output frequency (MCTRL1−NOUT+SLIP) A selection in C0111 is copied into
C0419/1. Change of C0419/1 sets
C0111 = 255!
2 (A) X3/63 (AOUT2−IN) 2 Apparent motor current (MCTRL1−IMOT)
3 (A) X3/A4 (DFOUT1−IN) 3 DC−bus voltage (MCTRL1−DCVOLT) Frequency output: 50 Hz ... 10 kHz
C0419

(cont.)
Possible analog signals for C0419  7−59
0 Output frequency (MCTRL1−NOUT+SLIP) 6 V/12 mA/5.85 kHz  C0011
1
Device utilisation (MCTRL1−MOUT) at V/f
characteristic control (C0014 = 2 or 3)
3 V/6 mA/2.925 kHz  Rated active inverter
current (active current/C0091)
Actual motor torque (MCTRL1−MACT) with vector
control (C0014 = 4) or sensorless torque control
(C0014 = 5)
3 V/6 mA/2.925 kHz  rated motor torque
2 Apparent motor current (MCTRL1−IMOT) 3 V/6 mA/2.925 kHz  rated inverter
current
3 DC−bus voltage (MCTRL1−DCVOLT) 6 V/12 mA/5.85 kHz  DC 1000 V (400 V
mains)
6 V/12 mA/5.85 kHz  DC 380 V (230 V
mains)
4 Motor power (MCTRL1−PMOT) 3 V/6 mA/2.925 kHz  rated motor power
5 Motor voltage (MCTRL1−VOLT) 4.8 V/9.6 mA/4.68 kHz rated motor
voltage
6 1/output frequency (1/C0050) (MCTRL1−1/NOUT) 2 V/4 mA/1.95 kHz  0.5  C0011
7 Output frequency within adjusted limits
(DCTRL1−C0010...C0011)
0 V/0 mA/4 mA/0 kHz  f = f
min
(C0010)
6 V/12 mA/5.85 kHz  f = f
max
(C0011)
8
Operation with process controller (C0238 = 0, 1):
Actual process controller value (PCTRL1−ACT)
6 V/12 mA/5.85 kHz  C0011
Operation without process controller (C0238 =
2):
Output frequency without slip (MCTRL1−NOUT)
