Commissioning
V/f characteristic control
5−8
L
EDB82MV752 EN 5.2
5.4.2 Commissioning with standard I/O function module
The following instructions apply to controllers equipped with a standard−I/O function module and a
three−phase AC motor which has been selected according to a power−based assignment.
1. Connect the keypad
2. Ensure that controller inhibit is active after mains connection
misc001
20 28
X3
}
Terminal X3/28 = LOW
3. Switch on the mains
ON
misc002
4. The keypad is in "Disp" mode after approx. 2 s and indicates
the output frequency (C0050)
000
000
abcd e
mno
p
qr
Hi
Hz
Lo
1
j gfkih PS
0050
The USEr menu is active
5. Change to the mode to configure the basic settings for
your drive
000
000
a
bcd e
mno
p
qr
Hi
Hz
Lo
1
j gfkih PS
0050
z
y
wx
Blinking on the display: 0050
6. Adapt the voltage/current range for the analog setpoint
selection (C0034)
Lenze setting: −0−, (0 ... 5 V/0 ... 10 V/0 ... 20 mA)
z
y
wx
0
000
abcd e
mno
p
qr
Hi
Lo
1
j gfkih PS
0034
Set the DIP switch on the standard I/O to the
same range (see Mounting Instructions for the
standard I/O)
7. Adapt the terminal configuration to the wiring (C0007)
Lenze setting: −0−, i. e.
E1: JOG1/3 fixed setpoint selection
E2: JOG2/3
E3: DCB DC injection brake
E4: CW/CCW rotation
z
y
wx
0
000
a
bcd e
mno
p
qr
Hi
Lo
1
j gfkih PS
0007
8. Set the minimum output frequency (C0010)
Lenze setting: 0.00 Hz
0 %
[f]
100 %
C0011
C0010
9. Set the maximum output frequency (C0011)
Lenze setting: 50.00 Hz
10. Set the acceleration time T
ir
(C0012)
Lenze setting: 5.00 s
[ H z ]
2
C 0 0 1 1
1
0
t
i r
t
i f
T
i r
T
i f
t
T
ir
t
ir
C0011
f
2
f
1
t
ir
= acceleration time wanted
11. Set the deceleration time T
if
(C0013)
Lenze setting: 5.00 s
T
if
t
if
C0011
f
2
f
1
t
if
= deceleration time wanted
12. Set the V/f−rated frequency (C0015)
Lenze setting: 50.00 Hz
100%
0
0 C0015
V
min
V
out
f
13. Set the V
min
boost (C0016)
Lenze setting: Depends on the controller type
The Lenze setting is suitable for all common
applications
