Function library
Free connection of digital signals, message output
7−73
L
EDB82MV752 EN 5.2
7.11.2 Free configuration of digital outputs
Description
The digital outputs (X3/A1, X3/A2, relay output K1
1
or digital switching output K1
2
) can be
linked freely with internal digital signals.
A signal source can be linked with several targets.
) Hinweis!
l C0008 enables the relay output K1
1
or the digital switching output K1
2
to be also
linked permanently with some internal signal sources. C0415/1 is then adapted
automatically.
l C0117 enables the digital output X3/A1 to be also linked permanently with some
internal signal sources. C0415/2 is then adapted automatically.
1) for device version 151
2) for device versions 152 and 153
Codes for parameter setting
Code Possible settings IMPORTANT
No. Name Lenze Selection
C0415
Free configuration
of digital outputs
Output of digital signals to terminals For configuration of relay output K2 see
C0409
7−73
1 Relay output K1
(RELAY, motec
version 151)
Digital switching
output K1 (motec
version 152, 153)
25 TRIP error message (DCTRL1−TRIP) A selection in C0008 is copied into
C0415/1. Change of C0415/1 sets
C0008 = 255!
2 Digital output X3/A1
(DIGOUT1)
16 Ready for operation (DCTRL1−RDY) A selection in C0117 is copied into
C0415/2. Change of C0415/2 sets
C0117 = 255!
3 (A) Digital output X3/A2
(DIGOUT2)
255 Not assigned (FIXED−FREE)
