Appendix
Attribute table
14−51
L
EDB82MV752 EN 5.2
14.7 Table of attributes
The data given in the table of attributes is required to write your own programs. It contains all
information for parameter communication with the controller.
How to read the table of attributes:
Column Meaning Entry
Code Name of the Lenze code Cxxxx
Index
dec
Index under which the parameter is
addressed The subindex of array variables
Is only required for control via INTERBUS,
PROFIBUS−DP or system bus (CAN)
hex
addressed. The subindex of array variables
corresponds to the Lenze subcode number.
PROFIBUS−DP or system bus (CAN).
Data DS Data structure
e Single variable (only one parameter element)
a Array variable (several parameter elements)
DT Data type
B8 1 byte bit−coded
B16 2 bytes bit−coded
B32 4 bytes bit−coded
FIX32 32 bit value with sign;
decimal with four decimal positions
I32 4 bytes with sign
U32 4 bytes without sign
VS ASCII string
Format LECOM format
VD ASCII decimal format
VH ASCII hexadecimal format
VS String format
VO Octet string format for data blocks
DA Number of array elements (subcodes) XX
DL Data length in bytes
Access R/W Remote Access authorisation for LECOM
Ra Reading is always permitted
Wa Writing is always permitted
w Writing is attached to a condition
R/W CAN Access authorisation for system bus (CAN)
Ra Reading is always permitted
Wa Writing is always permitted
w Writing is attached to a condition
Condition Condition for writing CINH Writing only permitted when controller is
inhibited
