Installation
Electrical installation − Connections
4−8
L
EDB82MV752 EN 5.2
4.2.3 Power connections
See corresponding Mounting Instructions
4.2.4 Control connections
The basic controller version is not provided with control terminals. Different I/O function modules are
available for the FIF interface to equip the controllers with control terminals.
4.2.4.1 Mounting/dismounting the I/O function module
See corresponding Mounting Instructions
