Function library
Display of operating data, diagnostics
7−86
L
EDB82MV752 EN 5.2
7.14 Display of operating data, diagnostics
7.14.1 Display of operating data
Description
Important operating parameters are measured by the controller. They can be displayed with the
keypad or PC.
Some operating data can be calibrated to be directly displayed or selected in the process variable
unit (e.g. pressure, temperature, speed).
) Note!
The calibration always effects all selected codes.
Codes for parameter setting
Code Possible settings IMPORTANT
No. Name Lenze Selection
C0004* Bar−graph display 56
1 {Code No.} 989
Bargraph display indicates the selected
value in % after power on
Range −180 % ... +180 %
56 = controller load (C0056)
C0044* Setpoint 2
(NSET1−N2)
−650.00 {0.02 Hz} 650.00 The value set will be lost when
switching the mains!
Selection, if C0412/2 = FIXED−FREE (not
assigned)
Display if C0412/2 is linked with a signal
source
7−45
C0046* Setpoint 1
(NSET1−N1)
−650.00 {0.02 Hz} 650.00 The value set will be lost when
switching the mains!
Selection, if C0412/1 = FIXED−FREE (not
assigned)
Display if C0412/1 is linked with a signal
source
7−45
C0047* Torque setpoint or
torque limit value
(MCTRL1−MSET)
400 0 {1 %} 400 The value set will be lost when
switching the mains!
7−10
Ref.: Rated motor torque detected by motor parameter
identification
Control mode "Sensorless torque control"
(C0014 = 5):
Torque setpoint selection if C0412/6 =
FIXED−FREE (not assigned)
Torque setpoint display if C0412/6 is
linked with a signal source
Control mode "V/f characteristic control" or
"Vector control" (C0014 = 2, 3, 4):
Torque limit value is displayed if
C0412/6 is linked with a signal source
C0047 = 400 is displayed if C0412/6 =
FIXED−FREE (not assigned)
C0049* Additional setpoint
(PCTRL1−NADD)
−650.00 {0.02 Hz} 650.00 The value set will be lost when
switching the mains!
Selection, if C0412/3 = FIXED−FREE (not
assigned)
Display if C0412/3 is linked with a signal
source
C0050*
uSEr
Output frequency
(MCTRL1−NOUT)
−650.00 {Hz} 650.00 Only display: Output frequency without slip
compensation
