Troubleshooting and fault elimination
Error message reset
8−7
L
EDB82MV752 EN 5.2
8.5 Resetting error messages
Eliminating the cause for TRIP error message
After eliminating the cause for a TRIP error message the error message must be reset with the "TRIP
reset" order. Only then the drive will start again.
) Note!
A TRIP error message can have several causes. The TRIP reset can only be carried
out after all causes for the TRIP have been eliminated.
Manual or automatic TRIP reset
You can select whether errors occurred are to be reset manually or automatically. Mains
disconnection always carries out a TRIP reset independent of the settings under C0170.
) Note!
If the controller carries out more than eight automatic TRIP resets within ten
minutes, the controller will set TRIP rST (Counter exceeded).
TRIP reset also resets the auto TRIP counter.
Codes for parameter setting
Code Possible settings IMPORTANT
No. Name Lenze Selection
C0043*
TRIP reset
0 No current error
Reset active error with C0043 = 0
1 Active fault
C0170
Configuration TRIP
reset
0
0 TRIP reset by mains switching, , LOW–signal
at X3/28, via function module or communication
module
TRIP reset via function module or
communication module with C0043,
C0410/12 or C0135 bit 11.
Auto TRIP reset after the time set under
C0171.
8−7
1 like 0 and additional auto TRIP reset
2 TRIP reset through mains switching, via function
module or communication module
3 TRIP reset by mains switching
C0171 Delay for auto−TRIP
reset
0.00 0.00 {0.01 sec} 60.00
