Installation
Mechanical installation − Important notes
4−1
L EDB82MV752 EN 5.2
4 Installation
4.1 Mechanical installation
4.1.1 Important notes
 The 8200 motec frequency inverter can be used in all operating positions.
 Free space:
– Allow a free space of 100 mm above and below the inverter.
– Ensure unimpeded ventilation of cooling air and outlet of exhaust air.
Tip!
The installation of compact drives, mechanical motor mounting or wall mounting is described in the
corresponding Mounting Instructions.
4.1.2 Mechanical design
Type Cable connections Weight
E82MV251_2B
E82MV371_2B
4 M20
(thread length 10 mm, without counter nut) 1.8 kg
2 M16
E82MV551_4B
E82MV751_4B
2 M25
(thread length 10 mm, without counter nut)
2.8 kg
4 M16
1 M20 for motor cable used for wall mounting (EMC cable connection)
(thread length 10 mm, with counter nut)
E82MV152_4B
E82MV222_4B
1 M20
(thread length 10 mm, without counter nut)
4.1 kg
2 M25
4 M16
1 M20 for motor cable used for wall mounting (EMC cable connection)
(thread length 10 mm, with counter nut)
E82MV302_4B
3 M25
4 M16
(thread length 10 mm, without counter nut) 9.7 kg
E82MV402_4B
E82MV552_4B
E82MV752_4B
