1. Introduction MMX8x4-HT series – User's Manual 11
Features
List of Features
DIFFERENCE: The availability of the features are device-dependent, see the table at the following page.
4K and 3D Support
High bandwidth allows extension of resolutions up to 4K and even 3D sources and displays are
supported.
Advanced Audio
Direct analog audio connection support to ease system integration. Advanced controls help to
inter-operate with an audio subsystem, audio sources or speakers directly.
Advanced EDID Management
Any EDID can be emulated on the inputs independently, read and store the attached monitor's
Audio Embedder and De-embedder Function
The analog audio can be embedded to HDMI outputs and embedded audio can be routed to
the analog audio output.
Audio Input Block for Microphone and Line-in
Special Audio Input block with input ports for microphone and line-in. The built-in sound mixer
allows for free mixing of the microphone, the line-in and the de-embedded audio.
LWR
Basic IT-security
Batch of Commands
CEC
Consumer Electronics Control (CEC)
Supports transmitting standard CEC commands in order to remote control the source or sink
device.
DSP
Event Manager
Event Manager +
features are available by the improved Event Manager.
Frame Detector
The exact video and audio signal format can be determined such as timing, frequencies, scan
mode, HDCP encryption, color range, color space and audio sample rate.
LCD
Graphic Display and Rotary Jog Dial Control Knob
Easy setting and menu navigation are assured by the color graphic display and the comfortable
jog dial control.
GPIO Control Port
commands.
HDCP-compliant
disabled when non-protected content is extended.
Infra Code Sending
IR code sending in Pronto Hex format – in Command injection mode, too. The code sending is
available as an Action in Event manager, too.
Miniweb
The Miniweb is able to display an adaptive surface with a virtual crosspoint and buttons for
Event manager Actions. The miniweb can be displayed in a mobile device, too.
Pixel Accurate Reclocking
Each output has a clean, jitter free signal, eliminating signal instability and distortion caused by
Relay
Remote Power (PoE)
Remote power (PoE-compatible) can be sent via the TPS ports to a compatible Powered
Device (PD).
RS-232
0100 1
x
RS-232 Recognizer
video conference codec devices.
TCP
0100 1
x
TCP Recognizer
video conference codec devices.
USB 2.0 Switch – 4x1
The USB 2.0 layer provides the switching of four external USB peripherals (e.g. webcamera,
speakerphone, multitouch display, etc.) to four independent host computers or laptops.
