MMX8x4-HT series – User's Manual 72
Presets Tab
presets even in the case of power down. The presets can be run from the front panel or by sending protocol
commands, too.
Loading a Preset
Step 1. Select the Presets tab from the Crosspoint menu.
Step 2. Select the desired preset; check the Preview panel and press the Load button. Press Yes in the
INFO: Presets which were saved by the front panel buttons previously are listed with names Preset1..
Preset8 as default. See the corresponding section.
Load
Saving a Preset
Step 1. Arrange the desired crosspoint connections.
Step 2. Select the Presets tab from the Crosspoint menu and choose a target preset slot from Preset 1.
Rename Preset button.
Step 3. Press the Save button and Yes
Renaming a Preset
Step 1. Select the desired preset you want to rename.
Step 2. Type the desired name and press the Rename Preset button.
Deleting a Preset
Step 1. Select the desired preset you want to delete.
Step 2. Press the Clear button and Yes
Auto Load Mode
Auto Load button is highlighted with green, the mode is active. In this case,
button is pressed.
Save
Rename preset
Clear
Auto Load
