Lightware MMX8x4-HT400MC User Manual


 MMX8x4-HT series – User's Manual 153

Set the Output Level of a GPIO Pin
Command and Response
ç <gpio_port><value>
æ <gpio_port><value>
Parameters
 Parameter description Parameter values
<gpio_port> GPIO port number P1-P6
<value>  H: High level
L: 
Example
ç 
æ 
Toggle the Level of a GPIO Pin
Command and Response
ç <gpio_port>:toggle()
æ <gpio_port>:toggle
Example
ç  
æ mO 
If the direction of the pin is input: the output value is toggled. If the direction of the pin is output: the output
value and the input value are toggled.
USB Port Settings
USB Host Select
Command and Response #usb
ç <USB_host>
æ <USB_host>
Parameters
 Parameter description Parameter values
<USB_host> Active USB-B port 1-4, 0 means off
Example
ç 
æ 
Power Switch Delay
Command and Response#usb
ç <delay_status>
æ <delay_status>
Parameters
 Parameter description Parameter values
<delay_status> 2sec Power-Cut
towards the devices if
Host changed
true
false
Example
ç 
æ 
Host 5V Sense
Command and Response
ç <HostPc>
æ <HostPc><status>
Parameters
 Parameter description Parameter values
<HostPc> ID of the host PC Host5vSensePc1
Host5vSensePc2
Host5vSensePc3
Host5vSensePc4
<status> Status of the
connected host
true
false
Example
ç 
æ 





Lightware MMX8x4-HT400MC Specifications

General

Category	Matrix Switcher
Model	MMX8x4-HT400MC
Input Ports	8
Output Ports	4
Video bandwidth	18 Gbps
3D Support	Yes
Ethernet	Yes
RS-232	Yes
EDID Management	Yes
Power Supply	100-240 VAC, 50/60 Hz
Supported Video Formats	HDMI, DisplayPort
HDCP	2.2
Audio Formats	Dolby Digital, DTS
Control Interface	RS-232
Rack Mount	Yes (1U)
Weight	3.5 kg
