5. Device Concept MMX8x4-HT series – User's Manual 45
TCP Recognizer
DIFFERENCE:
The feature is almost the same as in case of the RS-232 but for the network interface: the incoming TCP
Event Manager gives numerous opportunities for creating automatic room solutions.
TCP Recognizer Example
Step 1. TCP Clients (TCP Message
section).
Step 2. Create the following event in the Event manager:
E1.(PWR!001 "On")
low level.
Event Manager section.
Ethernet Interface - Example
Ethernet and TPS Connectors for LAN
The concept
Control Ethernet port to the Ethernet switch.
Ethernet Link to TPS inputs and TPS inputs Ethernet makes
possible to support TPS input ports (I1-4) with Ethernet.
In the room 2. a third-party Ethernet device connects to the TPS input port (I2). In this case, instead of TPS
In the room 3. the TPS extender connects to the TPS input port (I4)of the Matrix. Besides the TPS data
Settings
Matrix:
(P8) can be enabled.
To Next Page
