[ IX Troubleshooting ]
- 109 -
HWE10060 GB
3. Operation status before error
Setting procedure
Step 1
Set the dip switches
SW2 and SW3.
Set the dip switches on the circuit board as follows to view the operation status before
error.
SW2 SW3
105678910
ON OFFOFFOFFOFFOFFOFF
Step 2
Select the desired
item with the push
switch SWP3.
Press the push switch SWP3 to toggle through the item codes listed below.
Step 3
Press the push
switches SWP1 (↑) or
SWP2 (↓) to increase
or decrease the value.
Select an item code, and press either of the push switches SWP1 or SWP2 to display
the data acquisition time (operation data before error; 0 minute before = error occur-
rence time) and data type. They will appear alternately at one-second intervals.
Every time SWP2 is pressed, the time will go back by one minute, and the time and the
temperature (or pressure) will appear alternately at one-second intervals.
Each time SWP1 is pressed, the time will advance by one minute, and the time and the
temperature (or pressure) will appear alternately at one-second intervals.
The time immediately before the occurrence of error is defined as 0, and the time can
go back up to 19 minutes in one-minute increments.
Up to 20 collections of data can be viewed for each operation data.
Refer to "Time of data storage before error" for the types of errors that appear on error
history.
Step 4
Press the push switch
SWP3 to save the
change.
Press SWP3 to stop the blinking and return to the item code display.
