X Attachments
[1] R407C saturation temperature table
0.00 - 43.63 - 36.63
0.01 - 41.65 - 34.69
0.02 - 39.81 - 32.88
0.03 - 38.08 - 31.18
0.04 - 36.46 - 29.59
0.05 - 34.92 - 28.08
0.06 - 33.46 - 26.65
0.07 - 32.07 - 25.28
0.08 - 30.75 - 23.98
0.09 - 29.47 - 22.73
0.10 - 28.25 - 21.53
0.11 - 27.08 - 20.38
0.12 - 25.94 - 19.27
0.13 - 24.85 - 18.20
0.14 - 23.79 - 17.16
0.15 - 22.77 - 16.15
0.16 - 21.77 - 15.18
0.17 - 20.81 - 14.23
0.18 - 19.87 - 13.31
0.19 - 18.96 - 12.42
0.20 - 18.07 - 11.55
0.21 - 17.20 - 10.70
0.22 - 16.36 - 9.87
0.23 - 15.53 - 9.07
0.24 - 14.73 - 8.28
0.25 - 13.94 - 7.50
0.26 - 13.17 - 6.75
0.27 - 12.41 - 6.01
0.28 - 11.67 - 5.29
0.29 - 10.95 - 4.58
0.30 - 10.24 - 3.88
0.31 - 9.54 - 3.20
0.32 - 8.85 - 2.53
0.33 - 8.18 - 1.87
0.34 - 7.52 - 1.22
0.35 - 6.87 - 0.59
0.36 - 6.23 0.04
0.37 - 5.60 0.65
0.38 - 4.98 1.26
0.39 - 4.37 1.85
0.40 - 3.77 2.44
0.41 - 3.18 3.01
0.42 - 2.60 3.58
0.43 - 2.03 4.14
0.44 - 1.46 4.70
0.45 - 0.91 5.24
0.46 - 0.36 5.78
0.47 0.19 6.31
0.48 0.72 6.83
0.49 1.25 7.34
0.50 1.77 7.85
0.51 2.29 8.36
0.52 2.80 8.85
0.53 3.30 9.34
0.54 3.80 9.83
0.55 4.29 10.31
0.56 4.77 10.78
0.57 5.25 11.25
0.58 5.73 11.71
0.59 6.20 12.17
0.60 6.66 12.62
0.61 7.12 13.07
0.62 7.58 13.51
0.63 8.03 13.95
0.64 8.47 14.39
0.65 8.91 14.82
0.66 9.35 15.24
0.67 9.78 15.66
0.68 10.21 16.08
0.69 10.63 16.49
0.70 11.05 16.90
0.71 11.47 17.30
0.72 11.88 17.71
0.73 12.29 18.10
0.74 12.70 18.50
0.75 13.10 18.89
0.76 13.50 19.27
0.77 13.89 19.66
0.78 14.28 20.04
0.79 14.67 20.41
0.80 15.05 20.79
0.81 15.43 21.16
0.82 15.81 21.53
0.83 16.19 21.89
0.84 16.56 22.25
0.85 16.93 22.61
0.86 17.30 22.97
0.87 17.66 23.32
0.88 18.02 23.67
0.89 18.38 24.02
0.90 18.73 24.36
0.91 19.09 24.70
0.92 19.44 25.04
0.93 19.78 25.38
0.94 20.13 25.72
0.95 20.47 26.05
0.96 20.81 26.38
0.97 21.15 26.71
0.98 21.49 27.03
0.99 21.82 27.35
1.00 22.15 27.68
1.01 22.48 27.99
1.02 22.80 28.31
1.03 23.13 28.62
1.04 23.45 28.94
1.05 23.77 29.25
1.06 24.09 29.56
1.07 24.41 29.86
1.08 24.72 30.17
1.09 25.03 30.47
1.10 25.34 30.77
1.11 25.65 31.07
1.12 25.96 31.36
1.13 26.26 31.66
1.14 26.56 31.95
1.15 26.86 32.24
1.16 27.16 32.53
1.17 27.46 32.82
1.18 27.76 33.10
1.19 28.05 33.39
1.20 28.34 33.67
1.21 28.63 33.95
1.22 28.92 34.23
1.23 29.21 34.51
1.24 29.50 34.78
1.25 29.78 35.06
1.26 30.06 35.33
1.27 30.34 35.60
1.28 30.62 35.87
1.29 30.90 36.14
1.30 31.18 36.41
1.31 31.45 36.67
1.32 31.73 36.94
1.33 32.00 37.20
1.34 32.27 37.46
1.35 32.54 37.72
1.36 32.81 37.98
1.37 33.07 38.24
1.38 33.34 38.49
1.39 33.60 38.75
1.40 33.87 39.00
1.41 34.13 39.25
1.42 34.39 39.50
1.43 34.65 39.75
1.44 34.91 40.00
1.45 35.16 40.25
1.46 35.42 40.49
1.47 35.67 40.74
1.48 35.92 40.98
1.49 36.18 41.22
1.50 36.43 41.46
1.51 36.68 41.70
1.52 36.92 41.94
1.53 37.17 42.18
1.54 37.42 42.42
1.55 37.66 42.65
1.56 37.91 42.89
1.57 38.15 43.12
1.58 38.39 43.35
1.59 38.63 43.58
1.60 38.87 43.81
1.61 39.11 44.04
1.62 39.35 44.27
1.63 39.58 44.50
1.64 39.82 44.72
1.65 40.05 44.95
1.66 40.29 45.17
1.67 40.52 45.40
1.68 40.75 45.62
1.69 40.98 45.84
1.70 41.21 46.06
1.71 41.44 46.28
1.72 41.67 46.50
1.73 41.90 46.71
1.74 42.12 46.93
1.75 42.35 47.15
1.76 42.57 47.36
1.77 42.79 47.57
1.78 43.02 47.79
1.79 43.24 48.00
1.80 43.46 48.21
1.81 43.68 48.42
1.82 43.90 48.63
1.83 44.11 48.84
1.84 44.33 49.05
1.85 44.55 49.25
1.86 44.76 49.46
1.87 44.98 49.66
1.88 45.19 49.87
1.89 45.41 50.07
1.90 45.62 50.28
1.91 45.83 50.48
1.92 46.04 50.68
1.93 46.25 50.88
1.94 46.46 51.08
1.95 46.67 51.28
1.96 46.88 51.48
1.97 47.08 51.67
1.98 47.29 51.87
1.99 47.50 52.07
2.00 47.70 52.26
2.01 47.91 52.46
2.02 48.11 52.65
2.03 48.31 52.84
2.04 48.51 53.04
2.05 48.71 53.23
2.06 48.92 53.42
2.07 49.12 53.61
2.08 49.31 53.80
2.09 49.51 53.99
2.10 49.71 54.18
2.11 49.91 54.37
2.12 50.11 54.55
2.13 50.30 54.74
2.14 50.50 54.92
2.15 50.69 55.11
2.16 50.89 55.29
2.17 51.08 55.48
2.18 51.27 55.66
2.19 51.46 55.84
2.20 51.66 56.02
2.21 51.85 56.21
2.22 52.04 56.39
2.23 52.23 56.57
2.24 52.42 56.75
2.25 52.60 56.93
2.26 52.79 57.10
2.27 52.98 57.28
2.28 53.17 57.46
2.29 53.35 57.63
2.30 53.54 57.81
2.31 53.72 57.99
2.32 53.91 58.16
2.33 54.09 58.33
2.34 54.27 58.51
2.35 54.46 58.68
2.36 54.64 58.85
2.37 54.82 59.02
2.38 55.00 59.20
2.39 55.18 59.37
2.40 55.36 59.54
2.41 55.54 59.71
2.42 55.72 59.88
2.43 55.90 60.04
2.44 56.08 60.21
2.45 56.26 60.38
2.46 56.43 60.55
2.47 56.61 60.71
2.48 56.78 60.88
2.49 56.96 61.05
2.50 57.14 61.21
2.51 57.31 61.37
2.52 57.48 61.54
2.53 57.66 61.70
2.54 57.83 61.86
2.55 58.00 62.03
2.56 58.17 62.19
2.57 58.35 62.35
2.58 58.52 62.51
2.59 58.69 62.67
2.60 58.86 62.83
2.61 59.03 62.99
2.62 59.20 63.15
2.63 59.36 63.31
2.64 59.53 63.47
2.65 59.70 63.62
2.66 59.87 63.78
2.67 60.04 63.94
2.68 60.20 64.09
2.69 60.37 64.25
2.70 60.53 64.40
2.71 60.70 64.56
2.72 60.86 64.71
2.73 61.03 64.87
2.74 61.19 65.02
2.75 61.35 65.17
2.76 61.52 65.33
2.77 61.68 65.48
2.78 61.84 65.63
2.79 62.00 65.78
2.80 62.16 65.93
2.81 62.33 66.08
2.82 62.49 66.23
2.83 62.65 66.38
2.84 62.81 66.53
2.85 62.97 66.68
2.86 63.12 66.83
2.87 63.28 66.98
2.88 63.44 67.12
2.89 63.60 67.27
2.90 63.76 67.42
2.91 63.91 67.56
2.92 64.07 67.71
2.93 64.22 67.85
2.94 64.38 68.00
2.95 64.54 68.14
2.96 64.69 68.29
2.97 64.85 68.43
2.98 65.00 68.58
2.99 65.15 68.72
3.00 65.31 68.86
3.01 65.46 69.00
3.02 65.61 69.14
3.03 65.77 69.29
3.04 65.92 69.43
3.05 66.07 69.57
3.06 66.22 69.71
3.07 66.37 69.85
3.08 66.52 69.99
3.09 66.67 70.13
3.10 66.82 70.26
3.11 66.97 70.40
3.12 67.12 70.54
3.13 67.27 70.68
3.14 67.42 70.82
3.15 67.57 70.95
3.16 67.71 71.09
3.17 67.86 71.22
3.18 68.01 71.36
3.19 68.16 71.50
3.20 68.30 71.63
3.21 68.45 71.77
3.22 68.59 71.90
3.23 68.74 72.03
3.24 68.88 72.17
3.25 69.03 72.30
3.26 69.17 72.43
3.27 69.32 72.57
3.28 69.46 72.70
3.29 69.61 72.83
3.30 69.75 72.96
3.31 69.89 73.09
3.32 70.03 73.22
3.33 70.18 73.35
3.34 70.32 73.48
3.35 70.46 73.61
3.36 70.60 73.74
3.37 70.74 73.87
3.38 70.88 74.00
3.39 71.02 74.13
3.40 71.17 74.26
3.41 71.31 74.38
3.42 71.44 74.51
3.43 71.58 74.64
3.44 71.72 74.76
3.45 71.86 74.89
3.46 72.00 75.02
3.47 72.14 75.14
3.48 72.28 75.27
3.49 72.41 75.39
3.50 72.55 75.52
3.51 72.69 75.64
3.52 72.83 75.76
3.53 72.96 75.89
3.54 73.10 76.01
3.55 73.23 76.13
3.56 73.37 76.26
3.57 73.51 76.38
3.58 73.64 76.50
3.59 73.78 76.62
3.60 73.91 76.74
3.61 74.04 76.86
3.62 74.18 76.99
3.63 74.31 77.11
3.64 74.45 77.23
3.65 74.58 77.35
3.66 74.71 77.46
3.67 74.85 77.58
3.68 74.98 77.70
3.69 75.11 77.82
3.70 75.24 77.94
3.71 75.37 78.06
3.72 75.51 78.17
3.73 75.64 78.29
3.74 75.77 78.41
3.75 75.90 78.52
3.76 76.03 78.64
3.77 76.16 78.76
3.78 76.29 78.87
3.79 76.42 78.99
3.80 76.55 79.10
3.81 76.68 79.22
3.82 76.81 79.33
3.83 76.94 79.44
3.84 77.07 79.56
3.85 77.19 79.67
3.86 77.32 79.78
3.87 77.45 79.89
3.88 77.58 80.01
3.89 77.71 80.12
3.90 77.83 80.23
3.91 77.96 80.34
3.92 78.09 80.45
3.93 78.22 80.56
3.94 78.34 80.67
3.95 78.47 80.78
3.96 78.59 80.89
3.97 78.72 81.00
3.98 78.85 81.11
3.99 78.97 81.22
Saturation pressure
Saturating temperature °C
Saturated liquid
Saturated gas
MPa(gauge)
Saturation pressure
Saturating temperature °C
Saturated liquid
Saturated gas
MPa(gauge)
Saturation pressure
Saturating temperature °C
Saturated liquid
Saturated gas
MPa(gauge)
Saturation pressure
Saturating temperature °C
Saturated liquid
Saturated gas
MPa(gauge)
Saturation pressure
Saturating temperature °C
Saturated liquid
Saturated gas
MPa(gauge)
