PARAMETERS
92
4.2.20 Monitor display (Pr. 52, Pr. 54, Pr. 158)
Pr. 52 "control panel/PU main display
data selection"
Pr. 54 "FM terminal function selection"
Pr. 158 "AM terminal function selection"
You can select the signal displayed on the control panel (FR-PA02-
02
)/parameter unit
(FR-PU04) main display screen and the signal output to the FM terminal (100V class,
200V class) and AM terminal (400V class).
<100V class, 200V class>
!
Output terminal: Terminal FM (pulse train output)
!
Output signal selection: Pr. 54 "FM terminal function selection"
<400V class>
!
Output terminal: Terminal AM (analog output)
!
Output signal selection: Pr. 158 "AM terminal function selection"
Parameter
Number
Factory
Setting
Setting
Range
52 0 0, 23, 100
54 0 0, 1, 2
158 0 0, 1, 2
<Setting>
Set Pr. 52, Pr. 54 and Pr. 158 in accordance with the following table:
Parameter Setting
Pr. 52 Pr. 54 Pr. 158
Signal Type Unit
Control
panel
LED
PU main
monitor
FM
terminal
AM
terminal
Full-Scale Value of
FM, AM Level Meter
Output
frequency
Hz 0/100 0/100 0 0 Pr. 55
Output current A 0/100 0/100 1 1 Pr. 56
Output voltage
0/100 0/100 2 2 400V or 800V
Alarm display
0/100 0/100
××
Actual
operation time
10h 23 23
××
Pr. 37 "speed display"
Pr. 55 "frequency monitoring
reference"
Pr. 56 "current monitoring
reference"
Pr. 171 "actual operation hour
meter clear"
Pr. 900
"FM terminal calibration"
Pr. 901
"AM terminal calibration"
Related parameters
4
