Pr. 903 "frequency setting voltage gain"
(Pr.902, Pr. 904, Pr. 905 can also be adjusted similarly.)
<Adjustment procedure>
When using an external frequency setting signal to set the
frequency.
(1)Power-on (monitoring mode)
PU
MODE SET REV
STOP
RESET
FWD
MON
Hz
(2)Choose the PU operation mode.
1) Using the
MODE
key, make sure that the PU operation mode has been selected.
"
Monitoring mode
MODE
"
Frequency setting
mode
Hz
PU
Hz
PU
MON
"
Parameter setting
mode
PU
"
Help mode
PU
"
Operation mode
(PU operation mode)
PU
MODE SET REV
STOP
RESET
FWD
MODE MODE
MODE
MODE
Confirm that the PU operation mode
( ) has been chosen.
In the JOG operation mode ( )
or external operation mode ( ),
press the / key to display .
If cannot be displayed by pressing
the / key in the external operation mode
( ).
(if Pr. 79 "operation mode selection"
≠
"0"),
refer to 2) and set "1" (PU operation mode)
in Pr. 79 "operation mode selection".
