PARAMETERS
71
4.1.3 Parameters recommended to be set by the user
We recommend the following parameters to be set by the user.
Set them according to the operation specifications, load, etc.
Parameter
Number
Name Application
1 Maximum frequency
2 Minimum frequency
Used to set the maximum and minimum output
frequencies.
7 Acceleration time
8 Deceleration time
Used to set the acceleration and deceleration
times.
9
Electronic thermal O/L
relay
Used to set the current of the electronic
overcurrent protection to protect the motor from
overheat.
14 Load pattern selection
Used to select the optimum output characteristics
which match the application and load
characteristics.
71 Applied motor
Used to set the thermal characteristics of the
electronic overcurrent protection according to the
motor used.
73 0-5V/0-10V selection
Used to select the specifications of the frequency
setting signal entered across terminal 2-5 to
perform operation with the voltage input signal.
900 FM terminal calibration
Used to calibrate the meter connected across
terminals FM-SD.
901 AM terminal calibration
Used to calibrate the meter connected across
terminals AM-5.
902
Frequency setting voltage
bias
903
Frequency setting voltage
gain
904
Frequency setting current
bias
905
Frequency setting current
gain
Used to set the magnitude (slope) of the output
frequency relative to the frequency setting signal
(0 to 5V, 0 to 10V or 4 to 20mA DC) as desired.
