APPENDIX 1 Data Code List
202
APPENDIX
Appendix 1 Data Code List
Data Code
Func-
tion
Parameter
Number
Name
Read Write
Link Parameter Extension
Setting
(Data Code 7F/FF)
0
Torque boost 00 80 0
1
Maximum frequency 01 81 0
2
Minimum frequency 02 82 0
3
Base frequency 03 83 0
4
Multi-speed setting (high speed) 04 84 0
5
Multi-speed setting (middle speed) 05 85 0
6
Multi-speed setting (low speed) 06 86 0
7
Acceleration time 07 87 0
8
Deceleration time 08 88 0
Basic functions
9
Electronic thermal O/L relay 09 89 0
10
DC injection brake operation
frequency
0A 8A 0
11
DC injection brake operation time 0B 8B 0
12
DC injection brake voltage 0C 8C 0
13
Starting frequency 0D 8D 0
14
Load pattern selection 0E 8E 0
15
Jog frequency 0F 8F 0
16
Jog acceleration/deceleration time 10 90 0
18
High-speed maximum frequency 12 92 0
19
Base frequency voltage 13 93 0
20
Acceleration/deceleration
reference frequency
14 94 0
21
Acceleration/deceleration time
increments
15 95 0
22
Stall prevention operation level 16 96 0
23
Stall prevention operation level
compensation factor at double
speed
17 97 0
24
Multi-speed setting (speed 4) 18 98 0
25
Multi-speed setting (speed 5) 19 99 0
26
Multi-speed setting (speed 6) 1A 9A 0
27
Multi-speed setting (speed 7) 1B 9B 0
29
Acceleration/deceleration pattern 1D 9D 0
30
Regenerative function selection 1E 9E 0
31
Frequency jump 1A 1F 9F 0
32
Frequency jump 1B 20 A0 0
33
Frequency jump 2A 21 A1 0
34
Frequency jump 2B 22 A2 0
35
Frequency jump 3A 23 A3 0
36
Frequency jump 3B 24 A4 0
37
Speed display 25 A5 0
38
Frequency at 5V (10V) input 26 A6 0
Standard operation functions
39
Frequency at 20mA input 27 A7 0
