PARAMETERS
69
4.1.2 List of parameters classified by purpose of use
Set the parameters according to the operating conditions. The following list indicates
purpose of use and corresponding parameters.
Parameter Numbers
Purpose of Use
Parameter numbers which must be set
Operation mode selection Pr. 79
Acceleration/deceleration time/pattern
adjustment
Pr. 7, Pr. 8, Pr. 20, Pr. 21, Pr. 29
Selection of output characteristics
optimum for load characteristics
Pr. 3, Pr. 14, Pr. 19
Output frequency restriction (limit) Pr. 1, Pr. 2, Pr. 18
Operation over 60Hz Pr. 1, Pr. 18, Pr. 38, Pr. 39, Pr. 903, Pr. 905
Adjustment of frequency setting
signals and outputs
Pr. 38,Pr. 39, Pr. 73, Pr. 902 to Pr. 905
Motor output torque adjustment Pr. 0, Pr. 80
Brake operation adjustment Pr. 10, Pr. 11, Pr. 12
Multi-speed operation
Pr. 1, Pr. 2, Pr. 4, Pr. 5, Pr. 6, Pr. 15, Pr. 24,
Pr. 25, Pr. 26, Pr. 27, Pr. 232, Pr. 233, Pr. 234,
Pr. 235, Pr. 236, Pr. 237, Pr. 238, Pr. 239
Jog operation Pr. 15, Pr. 16
Frequency jump operation Pr. 31, Pr. 32, Pr. 33, Pr. 34, Pr. 35, Pr. 36
Automatic restart operation after
instantaneous power failure
Pr. 57, Pr. 58
Optimum acceleration/deceleration
within continuous rated range
Pr. 60
Slip compensation setting Pr. 245 to Pr. 247
Related to operation
Output stop method selection Pr. 250
General-purpose magnetic flux vector
control operation
Pr. 80
Electromagnetic brake operation timing Pr. 42, Pr. 190 to Pr. 192
Offline auto tuning setting Pr. 82 to Pr. 84, Pr. 90, Pr. 96
Sub-motor operation
Pr. 0, Pr. 3, Pr. 7, Pr. 8, Pr. 9, Pr. 44, Pr. 45,
Pr. 46, Pr. 47, Pr. 48
Regenerative function selection Pr. 30, Pr. 70
Operation in communication with
personal computer
Pr. 117 to Pr. 124, Pr. 342
Operation under PID control
Pr. 73, Pr. 79, Pr. 128 to Pr. 134, Pr. 180 to
Pr. 183, Pr. 190 to Pr. 192
Related to application operation
Noise reduction Pr. 72, Pr. 240
