1-3. DigiPackⅢ SPECIFICATION
Model Number:
J141-215 DigiPackⅢ.
Function:
Max 200 points Single head blow molding Parison programmer
Application:
Accumulator Based or Continuous Extrusion Blow Molding Machines
can be selected.
Profile Points:
10 to 200，Custom points. And Straight or Spline interpolation can be
selected.
Tooling Type:
Divergent or convergent die gap tooling types can be selected.
Tooling Position Control:
Digital closed loop servo system with a 1m sec update time.
Tooling Position Monitor:
From Tooling Position Actuator’s DCDT  10 VDC.
Accumulator Position Monitor:
From Accumulator Potentiometer 0 to 10 VDC FS.
Programming Inputs:
By Rotaly knob and touch panel switches.
Display:
Color Display (LCD). 10.1 inch(WXGA) touch screen.
English/Japanese/Chinese language selected by Parameter at Setup
screen.
Memory:
100 program profile patterns can be stored in a Flash RAM. And can
be stored in USB memory.
※ Supports standard USB memory, up to 32G. (Refer to 1-1. )
※ Data format: FAT32
Point Marker:
A marker output signal can be set maximum 10 program point.
Other Functions:
Shot Size, Delay, Cushion (for accumulator machines only), die gap,
data saving, profile curve adjustment (Weight and Range H/L), adjust-
ment of the tooling actuator stroke and the accumulator position trans-
ducer, backup for the system timer(by capacitor).
Output to Servovalve:
MFB type: ± 10, 20, 50, 100 mA or EFB type: ± 10 VDC
Servovalve Monitor:
± 100% Spool Stroke equals 4-20mA
I/O for Accumulator:
0 to 10 VDC transducer output and 10 V DC transducer excitation.
I/O for Tooling Position:
± 10 VDC DCDT output and ± 10 V DC DCDT excitation.
Common External Input:
Photo Coupler Isolated
Customer Supplied 15 to 24 Vdc @ 10 mA /Channel
24 VDC External Outputs:
Photo MOS Relay
Customer Supplied 15 to 24 Vdc @
100mA /Channel Max.
Accumulator type: End of Extrusion/Filling Relay Contacts:
250Vac @ 1 A/channel MAX.
Communication:
Data transfer with host computer by RS422 and Ethernet
Power Requirements:
24 VDC 0.5A min (MAX 3.0A depend on Servovalve Power required)
No ripple requirement : Max +-10 %
Temperature/Humidity:
0 to 45ºC within 85% relative humidity
IP rating
Front side = IP20, Rear side = IP30
Dimensions:
288 (W) x 240 (H) x 55 (D) mm (not include terminal)
Weight:
3.6 kg
