Figure 1-23 TB-2 Functions
※ Minimum acceptance time of digital input is 50msec or more
Name IN/OUT Function Comments (Refer Fig1-20, 1-21)
1 IN1 START IN Command for Cycle Start Enable machine cycle start.
2 IN2 DIE GAP IN Command to keep the tooling die gap It is valid at any time by continuous mode. Cycle is stops
at the set Die Gap value until IN1 START Accepted only at injection completion state (END EXT) at ACC mode
3 IN3 REBOOT IN Reboot switch for controller. Not accepted during machine cycle
4 IN4 STOP IN Command for Stop operation Cycle stop, hold at current position
A command to move the core from the current position to the position of the first point
Maintain position until start after moving completes.
The movement speed is set on the screen. Not accepted during machine cycle
10 IN10 EMERGENCY IN Servo OFF command. (E-Stop)
When it is High, the servo valve signal is stopped.
Because it is an emergency stop, accept at any time
ON = Emergency state
11 IN11 TEMP. OK IN Temperature rise completion confirmation.
When this signal is High, the servo valve signal is stopped.
ON = Temp not rised
12 NOT USE
13 INPUT COM.
14 INPUT COM.
15 NOT USE
16 24V DC
17 P GND
18 END FLG. OUT
ON at End of Filling.
Maintain until it falls below the position of End Filling
With this signal, the filling of the accumulation is stopped
19 END EXT. OUT ON at End of Extrusion. With this signal, the injection of the accumulation is stopped
In Continuous mode: ON until the next start.
※ In the case of Accum mode 1% hysteresis (injection & filling)
In Accumulator mode: ON while the accumulation position is smaller than
the injection completion position
20 MARKER OUT OUT Marker output signal. Output at the specified marker point Pulse width 200 msec
21 NOT USE
22 END ST SLOPE OUT At start slope input, ON at movement completion, maintain until IN1 start input
23 READY OUT Turn on when the start condition is set When this signal is ON, controller can receive the start signal.
※ This is not an interlock. Just inform to the host controller
24 ALARM OUT When both IN10 and IN11 are High and output (OFF=alarm state)
25 NOT USE
26 OUTPUT COM. Common for Digital Output Both Sink/Source support. For details see manual page 25
27 NOT USE
28 EOF Relay COM END OF FILLING Relay Common
29 EOF Relay B END Relay Contact B (NC)
30 EOF Relay A END Relay Contact A (NO)
31 NOT USED
32 EOE Relay COM END OF EXTRUSION Relay Common
33 EOE Relay B END Relay Contact B (NC)
34 EOE Relay A END Relay Contact A (NO)
Common for Digital Input (Isolation)
Pin 13-14 is internally connected.
Both Sink/Source support. For details see manual page 25
Digital signal power supply for both IN/OUT
Maximum current out : 3.0A
Relay output、AC250V、Maximum 1A
Relay output、AC250V、Maximum 1A
